171661-1 TE Auto Wiring Male Female Connector Crimp Loose Pins Copper Tinned Terminal 1.8 Series

2. mold design
After the product analysis, the mold design starts. It is based on the characteristics of the different structures of the product, and the corresponding software is designed with the relevant software. Under the modern processing conditions of today, it specifically refers to the 3D mold and 2D ranking, which is the main task of mold designer.
1) 3D division
The division is also called the demolition. It refers to the use of mold software to separate the mold (blank) according to the product model, so as to obtain parts (front and rear molds) that form a mold cavity. Specifically, after shrinking the 3D model of the product, 3D software such as PRO/E, UG, etc. split the product into dynamic/fixed mold kernels, oblique roofs, sliders, inlaids, etc. 3D mold demolition is the most important core work in the design of the entire mold. Only after the model disassembling can we design data files for subsequent part processing of the dynamic and fixed molds in the mold, the dynamic and fixed mold kernels in the mold.
3D division does not just refer to software operations. If you simply think that you have the mold design, you can master the mold design, then it is wrong. A long time ago, the products were very simple, and the computer was not popular. Through the calculation of simple machine tools and human brain, the mold could be made. With the continuous improvement of product requirements, the structure of the product is becoming more and more complicated, and the molds can no longer make the mold through manual computing and ordinary machine tools. If the various complex curved parts of the product are involved, it is no longer possible to process the number of machine tools. However, the use of CNC processing must be prepared, and the knife path program must be prepared. First of all, there must be parts model. This part model is a 3D part that constitutes the mold, which is generated by automatically divide the computer by the computer. Therefore, for today's mold processing, there is no 3D division, and design and processing molds are unimaginable.
Although the 3D division is completed with the help of the software, the software is not a panacea. It does not know what structure and structure is there. Software is just replacing the brain for mathematical calculations, simplifying the program. You must know how to design the mold before you can use the software to express the design ideas. Do not understand the design of the mold structure and divide the mold. Whether the parts of the parts can be processed, and the structure is reasonable and unreasonable, it is uncertain.
To this day, the mold CAD/CAE/CAM technology has been popularized in large and small mold factories. Design mold parts, it is no longer necessary to calculate a lot of manual computing. design. Students at school must recognize this and work hard to master this skill so that they can catch up with the needs of the enterprise. Do not do short mold design theorists.
2) 2D ranking
The 2D ranking mainly refers to the drawing of the mold group (the picture). Of course, it also includes drawing parts, line cuts, discharge processing diagrams, etc. Drawings are very important for mold processing. Even under digital processing conditions, drawings still need drawings for multi -processing enterprises. Under normal circumstances, the designer must draw the mold engineering map after completing the 3D model for the use of the processing masters of the processing workshop. Clear, complete, and accurate mold engineering drawings are very necessary.
The 2D ranking is the same as the 3D division. It is very professional. It is not used by AutoCAD, and you can draw a mold map. This requires understanding the design of mold structure, and it is proficient in using mold design tool software to draw well. In specific rankings, many details and paintings are unique to expressing mold structures, and they need to be continuously practiced to master.

Simple instructions：

We have product Catalogue，please contact us on skype，WhatsApp or Email.

If you can't find a product on our website or catalog, We deal with over 10,000 items, our catalog doesn’t cover all products. And we are developing 100+ molds yearly, which means around 10 new products are created in our factory. So don’t go away, just send us your photo or part no, we’ll check for you.
