3 Pin / 3 pin 12015796 Plastic-case Vehicles Electro Car Connectors Automobile Connecto

3 pin 12015796 Plastic-case Vehicles Electro Car Connectors Automobile Connecto

Wanlian #:

Mfr. #: 12015796

Online Inquiry

    Wanlian part number:



    Original number:

    12015796

    Gender:

     Female

    Specification:

    Housing: PBT+G; PA66+GF; PA66; PBT; Nylon

    Type:

    Connector

    TUV, TS16949, ISO14001, ISO 9001, RoHS conform:

    Yes

    MOQ:

    No minimum order quantity

    Supply sample:

    Yes

    Customized drawing with Decal, Frosted, Print are available as request

    Yes

    Payment method:

    We accept Paypal, TT, Alipay, West Union etc.

    Transportation method:

    Air Transport: UPS, DHL, FEDEX etc; Sea Transport; Railway Transport; Freight Forwarding etc.

    Production Capacity:

    1000000pieces/Month

12015796






3. Coupling method of mechanical coupling
Generally, the mechanical coupling device follows the principle of conservation of energy, that is, the input power is equal to the output power. Different from the mechanical coupling mechanism can be divided into three types: torque coupling method, speed coupling method, and power coupling method.
(1) Coupling torque. The torque coupling refers to overlapping the input torque of the two power sources, and the coupling output speed is not the speed superposition of the two power sources. The typical gear power coupling structure is shown. The torque of the two power sources can be superimposed on the coupling gear. Due to the constraints of power conservation, the condition of the torque coupling device to achieve torque is that the input speed of the two power sources input a fixed proportional relationship, and cannot change the speed independently. Essence
(2) Speed coupling. The speed coupling means that the input speed coupling of the two power sources can be superimposed, and the synthetic torque is not a superposition of the input torque of the two power sources. in the typical planetary gear structure, the speed of the two power sources has nothing to do with each other and can control the input independently. Due to the constraint of power conservation, the synthetic torque and the two power source input torque have become a fixed proportional relationship, so the minimum torque can be independently controlled, and the minimum torque determines the other two torque.
The design of the hybrid vehicle power coupling system should meet the lowest energy consumption requirements to improve the power, economics and discharge of hybrid vehicles, thereby obtaining good socio -economic benefits and alleviating my country's energy tension and environmental pollution.




1. Torque coupling combined mixed power driver system

1. Torque coupled type

Hybrid vehicles generally use two power sources, which require two inputs and one output mechanical device. The parallel hybrid dynamic driver system may have a variety of different structures. The torque coupling method can be achieved through various methods such as gear coupling, magnetic field coupling, chain or band coupling. The common torque coupling type is shown in Figure 2.20 to 2.22. As shown in Figure 2.20, the transmission structure diagram is used, Figure 2.21 shows the electromagnetic coupling transmission structure diagram, and Figure 2.22 shows a fixed axis gear transmission structure diagram.

Figure 2.20 The mechanical coupling type of the transmission structure of the band or sprocket wheel

Figure 2.21 electromagnetic coupling transmission structure

It can be seen from the type of mechanical coupler that the dual -power source can be entered from different axes or directions of the coupler, or input from the same axis or direction. The former is called a double -axis coupling, and the latter is called a single -axis coupling. As shown in Figure 2.20 and Figure 2.22, the dual -axis power coupling mechanism is shown, and Figure 2.21 shows a single -axis power coupling structure.







Simple instructions:

We have product Catalogue,please contact us on skype,WhatsApp or Email.

If you can't find a product on our website or catalog, We deal with over 10,000 items, our catalog doesn’t cover all products. And we are developing 100+ molds yearly, which means around 10 new products are created in our factory. So don’t go away, just send us your photo or part no, we’ll check for you.

The Keywords of this product:Automotive Connectors Terminals Plugs
