5-0965906-1 5-965906-1 Copper-aluminum Bimetallic Crimp Lugs Cable Terminals

(3) Inserter

The plug -in is an electrical device between the connection between the connection between the line and the wire beam, between the wire beam and the power consumption equipment, between the wiring beam and the switch, also known as the connector. Because the connection is reliable and convenient for maintenance, it is widely used in the car. The insertifier cannot be loose and corroded. In order to ensure the reliable connection of the plug, there is a locking device on it, and in order to avoid errors in the installation, the inserter also makes different specifications and shapes.

The plug-in is composed of the wire terminal and the plastic shell or rubber shell, as shown in Figure 9-3. According to the needs of the wiring beam, there are several types of one, double or multi -road. There are many pluggers in the modern car beam. In order to avoid errors in assembly and installation, the inserter is also distinguished into different types of specifications, different shapes and colors.

There is an inverted spines on the connector's terminal, which is installed in the protective cover to prevent it from getting out. When unplug the inserter, you cannot pull the guide line directly. You should first unlock the lock buckle of the insert, and then pull the case to the two sides to pull the plug and the socket, as shown in Figure 9-4. Some plugs are locked with a wire buckle. After pressing down the wire buckle, the plug's plug and socket can be pulled out.

In order to ensure that the inserter can be reliably connected, some plugs have a dual locking mechanism, as shown in Figure 9-5, and the role is: lock the plug plug and socket to prevent the insert from getting off.

The dual locking mechanism has a main lock and two convex decisives on the plug plug, and the lock handle can be rotated on the socket. When the main lock is not locked, the two convex on the plug will prevent the secondary lock lock, as shown in Figure 9-5 (a); when the main lock is completely locked, the subcarring handle can be rotated and locked, as shown in Figure 9. 9 -5 (b) shown; when the main lock and the auxiliary lock are dual-lock, the plug is reliable to connect to the socket, as shown in Figure 9-5 (C), thereby preventing the insert from getting off.

When the intervener has a poor terminal contact or a wire disconnection failure, first unplug the plug plug and socket, and then use a small screw rotor or a special tool to remove the wire and terminal from the shell, repair or replace it before loading, and then install it before loading. Cultivated.

In the automotive circuit, there are separate control switches in each electric equipment or independent electricity system, such as light switch, light -changing switch, wiper switch, washing device switch, steering switch, emergency alarm switch, air -conditioning switch, reversing switch, reversing switch switch , Brake switch, speaker switch, etc.

Simple instructions：

We have product Catalogue，please contact us on skype，WhatsApp or Email.

If you can't find a product on our website or catalog, We deal with over 10,000 items, our catalog doesn’t cover all products. And we are developing 100+ molds yearly, which means around 10 new products are created in our factory. So don’t go away, just send us your photo or part no, we’ll check for you.
