7165-0119 For Automotive Waterproof Wire Blue Housing Connector Seal

The performance of the electric connector contact part

Basic properties are electrical, machinery, and environmental resistance. The former must meet the three aspects of contact resistance, insulation resistance, and insulation resistance. This is also the guarantee of the reliable transmission of light and electrical signals. In terms of machinery, it is necessary to consider the factors of plug -in and mechanical life. Most of the overall life span of this type of component is inserted 50 times.

Materials of Electric Connectors

The selection of pins and jack materials must first ensure that it has a high mechanical strength. Secondly, in order to prevent damage and loosening; the contact force must be strong, and the jack material also needs to ensure that it has high elasticity. The anti -fatigue resistance of the two and the performance of processing and molding require a certain guarantee. Most of the pins materials selected at present are brass.

Factors affecting contact parts reliability

Form of contact

There are three types of contact form, line, and face. Usually it is a point contact. But when its scope is expanded to a certain extent, it is both line or face contact. Relatively speaking, the more contact points, the corresponding contact resistance will be smaller, and the actual use effect will be better.

Contact pressure

Generally, the contact resistance generated instantly in all contact forms is large. With the increase of its contact area and corresponding points, the instantaneous voltage will be reduced because the corresponding contact resistance continues to decrease. Among them, the selection of jack elastic structure is particularly important.

Temperature effect

When the working temperature of the contact rises to a certain degree, the hardness of the pins and jack materials will decrease with the increase of the temperature, but the smaller the contact resistance, the less obvious this problem; the higher temperature It will accelerate oxidation of the contact surface of the two, and then exacerbate them, so some suppression is needed.

Corrosive metal substance

There are two types of chemical and electrochemical corrosion. Most of them are caused by external environmental pollution. This type of pollution substances can cause oxide layers to appear metal surface, which will cause its corresponding contact resistance to rise.

Simple instructions：

We have product Catalogue，please contact us on skype，WhatsApp or Email.

If you can't find a product on our website or catalog, We deal with over 10,000 items, our catalog doesn’t cover all products. And we are developing 100+ molds yearly, which means around 10 new products are created in our factory. So don’t go away, just send us your photo or part no, we’ll check for you.
