24 pin 348240245 34824-0245 Automobile Waterproof Cable Electrical Connector Wiring Socket 2.0 Series

At present, sensor applications in the field of power transmission and transformation are mainly concentrated in equipment asset monitoring, smart grids, open power systems and remote monitoring, including the measurement of parameters such as current, voltage, and electric field strength. Due to the strict use of power transmission and transformation facilities, there are higher requirements for sensors in terms of durability and measurement convenience.

In the process of power transmission and transformation, in addition to high-voltage cables, substations are also required to participate in the step-up/step-down of power. The substation is the backbone of the power grid and is also a relatively expensive piece of equipment. The models range from 60 kV to 1,000 kV. The substations in service can also be divided into hub stations, intermediate stations and terminal stations based on voltage and transmission status. Substations Not only does the equipment have a large installed capacity, but the address layout is also relatively scattered, so manual maintenance is extremely inconvenient. The intelligent maintenance system with sensors as the core can play a huge role in this type of equipment.

Taking gas insulated substation/switchgear (GIS) as an example, this type of high-voltage substation consists of circuit breaker (CB), disconnecting switch (DS), earthing switch (ES, FES), bus bar (BUS), current transformer (CT) ), voltage transformer (VT), lightning arrester (LA) and other high-voltage components. These components are installed in an independent metal enclosed module. The sealed environment generally uses SF6 (sulfur hexafluoride) as the insulating medium to play an electrical role. The function of insulation and arc extinguishing. However, maintenance of these properties depends on the density of the SF6 gas, and any form of gas leakage will reduce its density and thus affect the device's electrical performance. Therefore, the sensor is generally responsible for measuring the pressure within the shell to detect the internal gas density. Compared with directly detecting the gas density in the warehouse, such a measurement is much simpler, so the pressure parameter is used as an indicator for alarm triggering.

MULTI-BEAM Lite's small size and low-profile form factor are suitable for 1U power supply or power distribution systems, which not only meet the requirements of next-generation environments, but also provide high design flexibility for a variety of solutions.

MULTI-BEAM Lite is mainly used in data center infrastructure, including servers, racks, storage solutions and switches.

main advantage

Smaller form factor enables better airflow to other components on the PCB while saving valuable PCB space

Angled headers, angled receptacles, and straight receptacles provide coplanar and backplane applications for increased design flexibility

High power applications, up to 75A per contact; low power applications, up to 45A per contact; signal contacts provide excellent power density and voltage and signal requirements to meet critical power specifications and various Application requirements

Design flexibility and expandability to save tooling costs

Simple instructions：

We have product Catalogue，please contact us on skype，WhatsApp or Email.

If you can't find a product on our website or catalog, We deal with over 10,000 items, our catalog doesn’t cover all products. And we are developing 100+ molds yearly, which means around 10 new products are created in our factory. So don’t go away, just send us your photo or part no, we’ll check for you.
