Wanlian #: WL042Y2-2-21
Mfr. #: 7123-8345 MG610396
|
Wanlian part number: |
|
WL042Y2-2-21 |
|
Original number: |
|
7123-8345 MG610396 |
|
Gender: |
|
Female |
|
Specification: |
|
Housing: PBT+G; PA66+GF; PA66; PBT; Nylon |
|
Type: |
|
Connector |
|
TUV, TS16949, ISO14001, ISO 9001, RoHS conform: |
|
Yes |
|
MOQ: |
|
No minimum order quantity |
|
Supply sample: |
|
Yes |
|
Customized drawing with Decal, Frosted, Print are available as request |
|
Yes |
|
Payment method: |
|
We accept Paypal, TT, Alipay, West Union etc. |
|
Transportation method: |
|
Air Transport: UPS, DHL, FEDEX etc; Sea Transport; Railway Transport; Freight Forwarding etc. |
|
Production Capacity: |
|
1000000pieces/Month |
3. QR line beam design
(1) Design
The power distribution box (melting and relay) is the core of the entire vehicle electrical appliance. It plays the role of allocating loads, centralized power supply, saving space, simplifying wire beams, reducing costs and convenient maintenance. Generally, 2 to 3 power distribution boxes can be configured as needed. Some newly developed models have both electronic control functions, and central control boxes without contacts and fuse will also become more and more market.
(2) Selection of wire color
The selection of wire color is QC/T 414-1999 "Low -voltage wire color for automobiles".
(3) Selection of plug -in parts
① Use plugs according to the wire diameter and passing the current.
② Seal plug -in parts in the engine compartment.
③ Priority use of a dual -spring -type pressure -tight structure plug to reduce contact resistance.
(4) Wire beam bandage method
① Generally, tapes are used to wrap the tape in the cab.
② The tape is tightly wrapped in tape in the dashboard.
③ Flame -retardant ripples are bandaged on the floor or far from the engine.
④ The inside of the door and the luggage door generally uses a bandaging form of tape or industrial plastic cloth.
⑤ Some areas closer to the engine are used to use insulation glass silk sleeves or wiring bouquets of glass ribbons.
In addition to the above content, you should also pay attention to the distance between the anti-theft ECU and the read and write coil to prevent the signal transmission attenuation; the electrical components of each transmission signal such as oxygen sensor, the degeneration sensor, and the read and write coil should be selected. Line species such as shielding wires.
Simple instructions：
We have product Catalogue，please contact us on skype，WhatsApp or Email.
If you can't find a product on our website or catalog, We deal with over 10,000 items, our catalog doesn’t cover all products. And we are developing 100+ molds yearly, which means around 10 new products are created in our factory. So don’t go away, just send us your photo or part no, we’ll check for you.
